Soo ich habs nun auch geschafft
Seid gestern ist meine mini PV Anlage in Betrieb.
2x 300Wp Panel Phono Solar 300 Watt PS300P-20/UM
Wechselrichter Solax X1 Mini X1-0.7
Montage 30° Aufständerung auf der Garage (Hochkant-Motage)
zum Messen der Einspeisung myStrom Wifi Steckdose
Hausanschluss Aeotec 3 Phase Meter
Ich bin Mega zufrieden habe bis jetzt einen Peak von 579Watt erreicht.
Die Anbindung erfolgt lediglich über den homee Adapter in ioBroker.
Danke auch nochmal an @Micha und @medicus07 mit deren Vorarbeit ich den HEM in Node Red angelegt habe.
Habe mit dies hier mit Hilfe vom sourceanalytix Adapter noch um die summierten kwh Daten erweitert. (vllt. ist das ja was für den ein oder anderen, der nur aktuelle Verbräuche hat und diese gerne um Summen für Woche,Monat,Jahr etc. erweitern will)
Standby
Der Haartrockner ist sehr gut zu erkennen ^^
Prduktion in HEM
Produktion im myStrom Plug
Für alle die sich evtl. die selbe Frage stellen, wie ich:
Wie sehen die Messwerte aus, die homee bekommt…
-
der myStrom Plug übergibt positive Werte, trotz „falscher“ Einspeiserichtung (Produktion PV)
-
das Aeotec 3 Phasen Smart Meter am Hausanschluss gibt den aktuellen Verbrauch (über alle 3 Phasen) als positiven Wert (Netzbezug) bzw. negativen Wert (Einspeisung) wieder. (Hausanschluss)
Hiermit kann dann der Verbrauch und die Einspeisung ermittelt werden.
[
{
"id": "e46c0c4b.b5004",
"type": "tab",
"label": "HEM ID:9",
"disabled": false,
"info": ""
},
{
"id": "87819a11.36ec98",
"type": "join",
"z": "e46c0c4b.b5004",
"name": "",
"mode": "custom",
"build": "array",
"property": "payload",
"propertyType": "msg",
"key": "topic",
"joiner": "\\n",
"joinerType": "str",
"accumulate": false,
"timeout": "",
"count": "2",
"reduceRight": false,
"reduceExp": "",
"reduceInit": "",
"reduceInitType": "",
"reduceFixup": "",
"x": 570,
"y": 840,
"wires": [
[
"b6f074c8.afc228"
]
]
},
{
"id": "b6f074c8.afc228",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "Summe",
"func": "msg.payload = msg.payload[0] + msg.payload[1]\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 700,
"y": 840,
"wires": [
[
"e9090521.be0888"
]
]
},
{
"id": "e9090521.be0888",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "Vorzeichen +/-",
"func": "var wert = msg.payload\n\nif (wert < 0){\nreturn {payload:-wert};\n}\nif (wert >= 0){\nreturn {payload:wert};\n}\n\n\n\n",
"outputs": 1,
"noerr": 0,
"x": 860,
"y": 840,
"wires": [
[
"b6f1b4f4.257028",
"f19c823a.c2ea7"
]
]
},
{
"id": "1f4ca77f.b92429",
"type": "homeeDevice",
"z": "e46c0c4b.b5004",
"virtual-homee": "",
"name": "hEM",
"nodeId": "9",
"showNodeId": false,
"profile": "38",
"icon": "default",
"attributes": "[{\"id\":900,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":10000,\"current_value\":0,\"target_value\":0,\"last_value\":0,\"unit\":\"text\",\"step_value\":1,\"editable\":0,\"type\":84,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":1,\"data\":\"HM0000422\"},{\"id\":901,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":10000,\"current_value\":0,\"target_value\":0,\"last_value\":0,\"unit\":\"text\",\"step_value\":1,\"editable\":0,\"type\":45,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":1,\"data\":\"11.4.11\"},{\"id\":902,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":50000,\"current_value\":1700,\"target_value\":1700,\"last_value\":0,\"unit\":\"W\",\"step_value\":100,\"editable\":0,\"type\":264,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":903,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":50000,\"current_value\":2500,\"target_value\":2500,\"last_value\":0,\"unit\":\"W\",\"step_value\":100,\"editable\":0,\"type\":265,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":904,\"node_id\":9,\"instance\":0,\"minimum\":-50000,\"maximum\":50000,\"current_value\":258,\"target_value\":258,\"last_value\":0,\"unit\":\"W\",\"step_value\":100,\"editable\":0,\"type\":267,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":905,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":50000,\"current_value\":0,\"target_value\":200,\"last_value\":0,\"unit\":\"W\",\"step_value\":100,\"editable\":0,\"type\":268,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":906,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":50000,\"current_value\":0,\"target_value\":980,\"last_value\":0,\"unit\":\"W\",\"step_value\":100,\"editable\":0,\"type\":269,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":907,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":100,\"current_value\":0,\"target_value\":37,\"last_value\":0,\"unit\":\"%25\",\"step_value\":1,\"editable\":0,\"type\":273,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":908,\"node_id\":9,\"instance\":0,\"minimum\":-50000,\"maximum\":50000,\"current_value\":1180,\"target_value\":1180,\"last_value\":1240,\"unit\":\"W\",\"step_value\":100,\"editable\":0,\"type\":266,\"state\":1,\"last_changed\":1572785663,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":909,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":9999999,\"current_value\":0,\"target_value\":0,\"last_value\":0,\"unit\":\"kWh\",\"step_value\":1,\"editable\":0,\"type\":274,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":910,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":9999999,\"current_value\":0,\"target_value\":0,\"last_value\":0,\"unit\":\"kWh\",\"step_value\":1,\"editable\":0,\"type\":275,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":911,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":9999999,\"current_value\":0,\"target_value\":0,\"last_value\":0,\"unit\":\"kWh\",\"step_value\":1,\"editable\":0,\"type\":276,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":912,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":9999999,\"current_value\":0,\"target_value\":0,\"last_value\":0,\"unit\":\"kWh\",\"step_value\":1,\"editable\":0,\"type\":277,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":913,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":9999999,\"current_value\":0,\"target_value\":0,\"last_value\":0,\"unit\":\"kWh\",\"step_value\":1,\"editable\":0,\"type\":278,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"},{\"id\":914,\"node_id\":9,\"instance\":0,\"minimum\":0,\"maximum\":9999999,\"current_value\":0,\"target_value\":0,\"last_value\":0,\"unit\":\"kWh\",\"step_value\":1,\"editable\":0,\"type\":279,\"state\":1,\"last_changed\":1572785482,\"changed_by\":1,\"changed_by_id\":0,\"based_on\":4,\"data\":\"\"}]",
"x": 1770,
"y": 500,
"wires": [
[]
]
},
{
"id": "34c98d44.783ee2",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "Verbrauch ID:904",
"info": "",
"x": 1040,
"y": 800,
"wires": []
},
{
"id": "bc85f57d.c195f8",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "Produktion ID:908",
"info": "",
"x": 610,
"y": 580,
"wires": []
},
{
"id": "47103fa9.ef89f",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "Einspeisung ID:903",
"info": "",
"x": 1650,
"y": 120,
"wires": []
},
{
"id": "5631e726.6402c8",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "Netzbezug ID:902",
"info": "",
"x": 510,
"y": 420,
"wires": []
},
{
"id": "82c0fc49.e332e",
"type": "ioBroker in",
"z": "e46c0c4b.b5004",
"name": "Netzbezug ID:902",
"topic": "homee.1.EnergyMeter-14.TotalCurrentEnergyUse-37",
"payloadType": "value",
"onlyack": "",
"func": "all",
"gap": "",
"x": 90,
"y": 260,
"wires": [
[
"1ee0dc17.a2dc04"
]
]
},
{
"id": "a3cc3fc5.df94a",
"type": "ioBroker in",
"z": "e46c0c4b.b5004",
"name": "Produktion PV ID:908",
"topic": "homee.0.MeteringPlug-184.CurrentEnergyUse-718",
"payloadType": "value",
"onlyack": "",
"func": "all",
"gap": "",
"x": 100,
"y": 160,
"wires": [
[
"ae282009.ed014"
]
]
},
{
"id": "5203d9cb.aeeb88",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{\"attribute\":{\"id\":902,\"value\":{{payload}}}}",
"output": "json",
"x": 540,
"y": 520,
"wires": [
[
"1f4ca77f.b92429",
"524600f2.e2cf8"
]
]
},
{
"id": "9606b06c.480c4",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{\"attribute\":{\"id\":903,\"value\":{{payload}}}}",
"output": "json",
"x": 1660,
"y": 160,
"wires": [
[
"1f4ca77f.b92429",
"4ddd14a9.473c1c"
]
]
},
{
"id": "775c12c9.696c2c",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{\"attribute\":{\"id\":908,\"value\":{{payload}}}}",
"output": "json",
"x": 580,
"y": 620,
"wires": [
[
"1f4ca77f.b92429",
"70f90a56.46f534"
]
]
},
{
"id": "89ba010a.c5cb3",
"type": "change",
"z": "e46c0c4b.b5004",
"name": "",
"rules": [
{
"t": "set",
"p": "payload",
"pt": "msg",
"to": "$number(payload)",
"tot": "jsonata"
}
],
"action": "",
"property": "",
"from": "",
"to": "",
"reg": false,
"x": 350,
"y": 900,
"wires": [
[
"87819a11.36ec98"
]
]
},
{
"id": "b6f1b4f4.257028",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{\"attribute\":{\"id\":904,\"value\":{{payload}}}}",
"output": "json",
"x": 1040,
"y": 840,
"wires": [
[
"1f4ca77f.b92429",
"7066fbfb.e19b24"
]
]
},
{
"id": "ac752b2b.1cf608",
"type": "change",
"z": "e46c0c4b.b5004",
"name": "",
"rules": [
{
"t": "set",
"p": "payload",
"pt": "msg",
"to": "$number(payload)",
"tot": "jsonata"
}
],
"action": "",
"property": "",
"from": "",
"to": "",
"reg": false,
"x": 350,
"y": 840,
"wires": [
[
"87819a11.36ec98"
]
]
},
{
"id": "4e9fa297.0a332c",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "Vorzeichen auf -",
"func": "var wert = msg.payload\n\nreturn {payload:-wert};\n\n",
"outputs": 1,
"noerr": 0,
"x": 720,
"y": 160,
"wires": [
[
"581deb3.34a8314"
]
]
},
{
"id": "581deb3.34a8314",
"type": "join",
"z": "e46c0c4b.b5004",
"name": "",
"mode": "custom",
"build": "array",
"property": "payload",
"propertyType": "msg",
"key": "topic",
"joiner": "\\n",
"joinerType": "str",
"accumulate": false,
"timeout": "",
"count": "2",
"reduceRight": false,
"reduceExp": "",
"reduceInit": "",
"reduceInitType": "",
"reduceFixup": "",
"x": 910,
"y": 160,
"wires": [
[
"165b495.f674bb7"
]
]
},
{
"id": "165b495.f674bb7",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "Summe",
"func": "msg.payload = msg.payload[0] + msg.payload[1]\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 1060,
"y": 160,
"wires": [
[
"33827cf7.8eca64"
]
]
},
{
"id": "e9c4f3da.57722",
"type": "change",
"z": "e46c0c4b.b5004",
"name": "",
"rules": [
{
"t": "set",
"p": "payload",
"pt": "msg",
"to": "$number(payload)",
"tot": "jsonata"
}
],
"action": "",
"property": "",
"from": "",
"to": "",
"reg": false,
"x": 510,
"y": 220,
"wires": [
[
"581deb3.34a8314"
]
]
},
{
"id": "1f80ad58.968ce3",
"type": "change",
"z": "e46c0c4b.b5004",
"name": "",
"rules": [
{
"t": "set",
"p": "payload",
"pt": "msg",
"to": "$number(payload)",
"tot": "jsonata"
}
],
"action": "",
"property": "",
"from": "",
"to": "",
"reg": false,
"x": 510,
"y": 160,
"wires": [
[
"4e9fa297.0a332c"
]
]
},
{
"id": "33827cf7.8eca64",
"type": "switch",
"z": "e46c0c4b.b5004",
"name": "",
"property": "payload",
"propertyType": "msg",
"rules": [
{
"t": "lte",
"v": "0",
"vt": "num"
},
{
"t": "gt",
"v": "0",
"vt": "num"
}
],
"checkall": "true",
"repair": false,
"outputs": 2,
"x": 1210,
"y": 160,
"wires": [
[
"b7263344.e8ded"
],
[
"9606b06c.480c4"
]
]
},
{
"id": "b7263344.e8ded",
"type": "change",
"z": "e46c0c4b.b5004",
"name": "",
"rules": [
{
"t": "set",
"p": "payload",
"pt": "msg",
"to": "0",
"tot": "num"
}
],
"action": "",
"property": "",
"from": "",
"to": "",
"reg": false,
"x": 1390,
"y": 160,
"wires": [
[
"9606b06c.480c4"
]
]
},
{
"id": "cedf030f.46913",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "Zustände -> Attribute.ID",
"info": "902=Netzbezug\n903=Einspeisung\n904=Verbrauch\n905=Entladung\n906=Ladung\n907=Ladezustand\n908=Produktion\n909= Gesamt Verbrauch\n910= Gesamt Produktion\n911= Gesamt bezogene Energie Netz\n912=Gesamt eingespeißte Energie\n913=Gesamt gespeicherte Energie\n914=Gesamt bezogene Energie Speicher",
"x": 100,
"y": 40,
"wires": []
},
{
"id": "57bc0681.650738",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "Gesamt verbrauchte Energie aus SourceAnalytix ID:909",
"info": "",
"x": 1740,
"y": 800,
"wires": []
},
{
"id": "32962c6c.886734",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "Gesamt produzierte Energie aus SourceAnalytix ID:910",
"info": "",
"x": 1340,
"y": 580,
"wires": []
},
{
"id": "37f81e76.e742c2",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "bezogene Ernergie Netz aus SourceAnalytix ID:911",
"info": "",
"x": 1370,
"y": 420,
"wires": []
},
{
"id": "4510e429.99ff1c",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "eingespeißte Energie aus SourceAnalytix ID:912",
"info": "",
"x": 1480,
"y": 220,
"wires": []
},
{
"id": "2fb69a0e.0f6416",
"type": "ioBroker out",
"z": "e46c0c4b.b5004",
"name": "hem.verbrauch",
"topic": "node-red.0.hemGes.verbrauch",
"ack": "true",
"autoCreate": "true",
"x": 1420,
"y": 840,
"wires": []
},
{
"id": "7066fbfb.e19b24",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{{payload.attribute.value}}",
"output": "str",
"x": 1240,
"y": 840,
"wires": [
[
"2fb69a0e.0f6416"
]
]
},
{
"id": "c25e3a37.f6f5f8",
"type": "ioBroker out",
"z": "e46c0c4b.b5004",
"name": "hem.einspeisung",
"topic": "node-red.0.hemGes.einspeisung",
"ack": "true",
"autoCreate": "true",
"x": 1090,
"y": 260,
"wires": []
},
{
"id": "4ddd14a9.473c1c",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{{payload.attribute.value}}",
"output": "str",
"x": 900,
"y": 260,
"wires": [
[
"c25e3a37.f6f5f8"
]
]
},
{
"id": "5779c29a.f77e7c",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "objekt in iobroker für SourcAnalytix",
"info": "",
"x": 960,
"y": 220,
"wires": []
},
{
"id": "7a9f52d1.a4468c",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "objekt in iobroker für SourcAnalytix",
"info": "",
"x": 1340,
"y": 800,
"wires": []
},
{
"id": "ceff82fe.590c3",
"type": "ioBroker out",
"z": "e46c0c4b.b5004",
"name": "hem.produktionGes",
"topic": "node-red.0.hemGes.produktionGes",
"ack": "true",
"autoCreate": "true",
"x": 1050,
"y": 620,
"wires": []
},
{
"id": "70f90a56.46f534",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{{payload.attribute.value}}",
"output": "str",
"x": 800,
"y": 620,
"wires": [
[
"ceff82fe.590c3"
]
]
},
{
"id": "253fa937.4dbd56",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "objekt in iobroker für SourcAnalytix",
"info": "",
"x": 940,
"y": 580,
"wires": []
},
{
"id": "64859df.b855d64",
"type": "ioBroker out",
"z": "e46c0c4b.b5004",
"name": "hem.netzbezug",
"topic": "node-red.0.hemGes.netzbezug",
"ack": "true",
"autoCreate": "true",
"x": 1060,
"y": 460,
"wires": []
},
{
"id": "524600f2.e2cf8",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{{payload.attribute.value}}",
"output": "str",
"x": 820,
"y": 460,
"wires": [
[
"64859df.b855d64"
]
]
},
{
"id": "ce2bb934.7d6858",
"type": "comment",
"z": "e46c0c4b.b5004",
"name": "objekt in iobroker für SourcAnalytix",
"info": "",
"x": 960,
"y": 420,
"wires": []
},
{
"id": "3050acbb.534844",
"type": "ioBroker in",
"z": "e46c0c4b.b5004",
"name": "Verbr Ges",
"topic": "sourceanalytix.0.node-red__0__hemGes__verbrauch.Current_Reading",
"payloadType": "value",
"onlyack": "",
"func": "all",
"gap": "",
"x": 1600,
"y": 840,
"wires": [
[
"bbccdbfc.ba1958"
]
]
},
{
"id": "bbccdbfc.ba1958",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{\"attribute\":{\"id\":909,\"value\":{{payload}}}}",
"output": "json",
"x": 1760,
"y": 840,
"wires": [
[
"1f4ca77f.b92429"
]
]
},
{
"id": "c8859732.22cf38",
"type": "ioBroker in",
"z": "e46c0c4b.b5004",
"name": "Prod Ges",
"topic": "sourceanalytix.0.node-red__0__hemGes__produktionGes.Current_Reading",
"payloadType": "value",
"onlyack": "",
"func": "all",
"gap": "",
"x": 1240,
"y": 620,
"wires": [
[
"299a363a.fc753a"
]
]
},
{
"id": "299a363a.fc753a",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{\"attribute\":{\"id\":910,\"value\":{{payload}}}}",
"output": "json",
"x": 1400,
"y": 620,
"wires": [
[
"1f4ca77f.b92429"
]
]
},
{
"id": "53af4072.b8d2",
"type": "ioBroker in",
"z": "e46c0c4b.b5004",
"name": "Netz Ges",
"topic": "sourceanalytix.0.node-red__0__hemGes__netzbezug.Current_Reading",
"payloadType": "value",
"onlyack": "",
"func": "all",
"gap": "",
"x": 1240,
"y": 460,
"wires": [
[
"c1fdb2cd.6f732"
]
]
},
{
"id": "c1fdb2cd.6f732",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{\"attribute\":{\"id\":911,\"value\":{{payload}}}}",
"output": "json",
"x": 1400,
"y": 460,
"wires": [
[
"1f4ca77f.b92429"
]
]
},
{
"id": "f9da1826.911628",
"type": "ioBroker in",
"z": "e46c0c4b.b5004",
"name": "Gesamt Einspeisung",
"topic": "sourceanalytix.0.node-red__0__hemGes__einspeisung.Current_Reading",
"payloadType": "value",
"onlyack": "",
"func": "all",
"gap": "",
"x": 1310,
"y": 260,
"wires": [
[
"83896735.b71828"
]
]
},
{
"id": "83896735.b71828",
"type": "template",
"z": "e46c0c4b.b5004",
"name": "",
"field": "payload",
"fieldType": "msg",
"format": "handlebars",
"syntax": "mustache",
"template": "{\"attribute\":{\"id\":912,\"value\":{{payload}}}}",
"output": "json",
"x": 1520,
"y": 260,
"wires": [
[
"1f4ca77f.b92429"
]
]
},
{
"id": "1ee0dc17.a2dc04",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "netz",
"func": "flow.set(\"netz\",msg.payload);\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 90,
"y": 320,
"wires": [
[]
]
},
{
"id": "ae282009.ed014",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "prod",
"func": "flow.set(\"prod\",msg.payload);\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 90,
"y": 220,
"wires": [
[]
]
},
{
"id": "385ebfe7.780d2",
"type": "inject",
"z": "e46c0c4b.b5004",
"name": "",
"topic": "",
"payload": "",
"payloadType": "num",
"repeat": "5",
"crontab": "",
"once": false,
"onceDelay": 0.1,
"x": 90,
"y": 540,
"wires": [
[
"ea7ea0a.031ec6",
"22b8706f.b90dd",
"df8d1c75.fb064",
"cabc8f47.5c7e4",
"516cdb86.97a2f4",
"143a5cd.5e614a3"
]
]
},
{
"id": "ea7ea0a.031ec6",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "prod",
"func": "msg.payload=flow.get(\"prod\");\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 330,
"y": 220,
"wires": [
[
"e9c4f3da.57722"
]
]
},
{
"id": "22b8706f.b90dd",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "prod",
"func": "msg.payload=flow.get(\"prod\");\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 430,
"y": 620,
"wires": [
[
"775c12c9.696c2c"
]
]
},
{
"id": "df8d1c75.fb064",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "netz",
"func": "msg.payload=flow.get(\"netz\");\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 210,
"y": 480,
"wires": [
[
"3afb6f6e.efcf6"
]
]
},
{
"id": "f19c823a.c2ea7",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "",
"func": "flow.set(\"verb\",msg.payload);\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 1050,
"y": 920,
"wires": [
[]
]
},
{
"id": "cabc8f47.5c7e4",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "verb",
"func": "msg.payload=flow.get(\"verb\");\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 330,
"y": 160,
"wires": [
[
"1f80ad58.968ce3"
]
]
},
{
"id": "3afb6f6e.efcf6",
"type": "switch",
"z": "e46c0c4b.b5004",
"name": "",
"property": "payload",
"propertyType": "msg",
"rules": [
{
"t": "lte",
"v": "0",
"vt": "num"
},
{
"t": "gt",
"v": "0",
"vt": "num"
}
],
"checkall": "true",
"repair": false,
"outputs": 2,
"x": 350,
"y": 480,
"wires": [
[
"7da20557.57f33c"
],
[
"5203d9cb.aeeb88"
]
]
},
{
"id": "7da20557.57f33c",
"type": "change",
"z": "e46c0c4b.b5004",
"name": "",
"rules": [
{
"t": "set",
"p": "payload",
"pt": "msg",
"to": "0",
"tot": "num"
}
],
"action": "",
"property": "",
"from": "",
"to": "",
"reg": false,
"x": 570,
"y": 460,
"wires": [
[
"5203d9cb.aeeb88"
]
]
},
{
"id": "516cdb86.97a2f4",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "netz <> prod",
"func": "var netz = flow.get(\"netz\");\nvar prod = flow.get(\"prod\");\n\nif (netz < prod){\nreturn {payload:netz};\n}\nif (netz >= prod){\nreturn {payload:prod};\n}\n\n\n\n",
"outputs": 1,
"noerr": 0,
"x": 150,
"y": 840,
"wires": [
[
"ac752b2b.1cf608"
]
]
},
{
"id": "143a5cd.5e614a3",
"type": "function",
"z": "e46c0c4b.b5004",
"name": "netz <> prod",
"func": "var netz = flow.get(\"netz\");\nvar prod = flow.get(\"prod\");\n\nif (netz < prod){\nreturn {payload:prod};\n}\nif (netz >= prod){\nreturn {payload:netz};\n}\n\n\n\n",
"outputs": 1,
"noerr": 0,
"x": 150,
"y": 900,
"wires": [
[
"89ba010a.c5cb3"
]
]
}
]
ich hatte heute auch ein wenig was drauf. Bin nur noch nicht ganz zufrieden mit der aufsummieren
